Printers.pas의 사용법

TPrinter

// 생성, 소멸

constructor Create;

destructor Destroy; override;



// 인쇄 제어

procedure Abort; procedure BeginDoc;

procedure EndDoc;

procedure NewPage;

property Canvas: TCanvas ; //ReadOnly

property Copies: Integer;

property Orientation: TPrinterOrientation;

property Title: string ;



// 프린터 제어

procedure GetPrinter(ADevice, ADriver, APort: PChar; var ADeviceMode: THandle);

procedure SetPrinter(ADevice, ADriver, APort: PChar; ADeviceMode: THandle);

property Handle: HDC; //ReadOnly

property PrinterIndex: Integer ;

property Printers: TStrings; //ReadOnly



// 상태 정보

property Aborted: Boolean; //ReadOnly

property Capabilities: TPrinterCapabilities; //ReadOnly

property Fonts: TStrings; //ReadOnly

property PageHeight: Integer; //ReadOnly

property PageWidth: Integer; //ReadOnly

property PageNumber: Integer ; //ReadOnly

property Printing: Boolean; //ReadOnly



나. 전역Procedure, Function

function Printer: TPrinter;

function SetPrinter(NewPrinter: TPrinter): TPrinter;

procedure AssignPrn(var F: Text);









TCanvas의 사용법

// 생성, 소멸

constructor Create;

destructor Destroy; override;



// 직선그리기

procedure LineTo(X, Y: Integer);

procedure MoveTo(X, Y: Integer);

procedure Polyline(const Points: array of TPoint);

procedure PolyBezier(const Points: array of TPoint);

procedure PolyBezierTo(const Points: array of TPoint);



// 사각형 그리기

procedure FillRect(const Rect: TRect);

procedure DrawFocusRect(const Rect: TRect);

procedure FrameRect(const Rect: TRect);

procedure Rectangle(X1, Y1, X2, Y2: Integer);

procedure RoundRect(X1, Y1, X2, Y2, X3, Y3: Integer);



// 원 그리기

procedure Arc(X1, Y1, X2, Y2, X3, Y3, X4, Y4: Integer);

procedure Ellipse(X1, Y1, X2, Y2: Integer);

procedure Pie(X1, Y1, X2, Y2, X3, Y3, X4, Y4: Integer);

procedure Chord(X1, Y1, X2, Y2, X3, Y3, X4, Y4: Integer);



// 다각형 그리기

procedure Polygon(const Points: array of TPoint);



// 채우기

procedure FloodFill(X, Y: Integer; Color: TColor; FillStyle: TFillStyle);



// 비트맵 처리

procedure BrushCopy(const Dest: TRect; Bitmap: TBitmap; const Source: TRect; Color:TColor);

procedure CopyRect(const Dest: TRect; Canvas: TCanvas; const Source: TRect);

procedure Draw(X, Y: Integer; Graphic: TGraphic);

procedure StretchDraw(const Rect: TRect; Graphic: TGraphic);



// 문자열 관련

function TextExtent(const Text: string): TSize;

function TextHeight(const Text: string): Integer;

procedure TextOut(X, Y: Integer; const Text: string);

procedure TextRect(Rect: TRect; X, Y: Integer; const Text: string);

function TextWidth(const Text: string): Integer;



// 점찍기

property Pixels[X, Y: Integer]: TColor;



// 상태 제어

procedure Lock; procedure Unlock;

procedure Refresh; function TryLock: Boolean;



// 이벤트

property OnChange: TNotifyEvent;

property OnChanging: TNotifyEvent;



// 프로퍼티

property ClipRect: TRect; //ReadOnly

property Handle: HDC;

property LockCount: Integer ; //ReadOnly

property CanvasOrientation: TCanvasOrientation ; //ReadOnly

property PenPos: TPoint ;

property TextFlags: Longint;

property Brush: TBrush;

property CopyMode: TCopyMode;

property Font: TFont;

property Pen: TPen;







매핑모드

  : 각종 그리기 함수에서 사용하는 좌표의 단위를 나타내는 것을 말한다.





종류와 규격

이름 단위 X증가 방향 Y증가 방향

MM_TEXT Pixel 오른쪽 아래

MM_LOMETRIC 0.1 mm 오른쪽 위

MM_HIMETRIC 0.01 mm 오른쪽 위

MM_LOENGLISH 0.01 inch 오른쪽 위

MM_HIENGLISH 0.001 inch 오른쪽 위

MM_TWIPS 1/20 Point, 1/1440 inch 오른쪽 위

MM_ISOTROPIC 사용자정의 X,Y동일 사용자정의 사용자정의

MM_ANISOTROPIC 사용자정의 사용자정의 사용자정의





사용법

SetMapMode( Printer.Handle, MM_TEXT );

GetMapMode(Printer.Handle );





좌표 설정

- 절대 좌표

  용지의 크기와 관계없이 내용의 크기를 일정하게 한다.

- 상대 좌표

용지의 크기에 맞게 내용의 크기도 변한다.





문자 출력

- TextMetric의 구조

tagTEXTMETRIC = record tmHeight: Longint; //전체 높이

tmAscent: Longint; //베이스라인의 윗부분

tmDescent: Longint; //베이스라인의 아랫부분

tmInternalLeading: Longint; //경계 내부의 리딩

tmExternalLeading: Longint; //행간의 엑스트라 리딩

tmAveCharWidth: Longint; //문자의 평균 폭

tmMaxCharWidth: Longint; //가장 큰문자 가로 폭

tmWeight: Longint; //굵기

tmOverhang: Longint; //문자열간의 추가 폭

tmDigitizedAspectX: Longint; //수평 기준

tmDigitizedAspectY: Longint; //수직 기준

tmFirstChar: AnsiChar; //첫번째 문자

tmLastChar: AnsiChar; //마지막 문자

tmDefaultChar: AnsiChar; //글꼴에 없는 문자를 대체할 문자(네모)

tmBreakChar: AnsiChar; //단어 잘림을 정의하는데 사용되는 문자

tmItalic: Byte; //기울임꼴 <> 0

tmUnderlined: Byte; //밑줄 <> 0

tmStruckOut: Byte; //취소선 <> 0

tmPitchAndFamily: Byte; //글꼴의 피치,패미리 정보

tmCharSet: Byte; //문자세트

end;





프린터 제어

// 가로 해상도

function GetXDPI:Integer;

begin

  Result:= GetDeviceCaps( Printer.Handle, LOGPIXELSX );

end;



// 세로 해상도

function GetYDPI:Integer;

begin

  Result:= GetDeviceCaps( Printer.Handle, LOGPIXELSY );

end;



// 프린터가 가지고 있는 용지 여백

procedure GetOutSide( var ALeft, ATop, ARight, ABottom: Integer );

var

  Pt: TPoint;

begin

  Escape( Printer.Canvas.Handle, GETPRINTINGOFFSET, 0, nil, @Pt );

  ALeft := Pt.X; ATop := Pt.Y;



  Escape ( Printer.Canvas.Handle, GETPHYSPAGESIZE, 0, nil, @Pt );

  ARight := Pt.X - Printer.PageWidth - ALeft;

  ABottom:= Pt.Y - Printer.PageHeight - ATop ;

end;



// 0점 조절 { 0점 : 그리기 함수에서 X,Y축이 0이 되는 지점을 말한다 }

function SetOrgPoint( APoint: TPoint ): TSize;

var

  Org: TPoint;

begin

  Escape( Printer.Canvas.Handle, GETPRINTINGOFFSET, 0, nil, @Org );

  SetWindowOrgEx( Printer.Handle,Org.X-APoint.X,APoint.Y-Org.Y,@Result );

end;



// 매핑모드

procedure TMain_Form.Button10Click(Sender: TObject);

var

  OldMap: Integer; OldOrg: TSize;

begin

  Printer.BeginDoc;

  OldMap := SetMapMode( Printer.Handle, MM_LOMETRIC );

  OldOrg := SetOrgPoint( Point( 300, 1500 ) );



  try

    Printer.Canvas.Rectangle( 0, 0, 1000, -200 );

  finally

    SetOrgPoint( Point( OldOrg.cx, OldOrg.cy ) );

    SetMapMode( Printer.Handle, OldMap ); Printer.EndDoc;

  end;

end;









그리기



// 예제 1

procedure DrawLine( Canvas: TCanvas );

begin

  with Canvas do

  begin

    //SetMapMode( MM_TEXT );



    Pen.Width := 1;

    MoveTo( 100, 100 );

    LineTo( 2000, 100 );



    Pen.Width := 3;

    MoveTo( 100, 200 );

    LineTo( 2000, 200 );



    Pen.Width := 5;

    MoveTo( 100, 400 );

    LineTo( 2000, 400 );



    Pen.Width := 10;

    MoveTo( 100, 600 );

    LineTo( 2000, 600 );



    Pen.Width := 20;

    MoveTo( 100, 800 );

    LineTo( 2000, 800 );



    Pen.Color := clRed;

    Brush.Color := clYellow;

    Ellipse( 100, 1000, 2000, 1200 );



    Pen.Color := clGreen;

    Brush.Color := clBlue;

    Rectangle( 100, 1400,11 2000, 1600 );



    Pen.Color := clMaroon;

    Brush.Color := clAqua;

    Rectangle( 100, 1800, 2000, 2000 );

    Brush.Color := clNavy;

    Brush.Style:= bsDiagCross;

    Rectangle( 100, 2200,2000, 2500 );

  end;

end;



procedure TMain_Form.Button1Click(Sender: TObject);

begin

  Printer.BeginDoc;

  DrawLine( Printer.Canvas );

  Printer.EndDoc;

end;







매핑모드를 mm, inch 단위나 사용자 정의형으로 바꿔서 그리기

// 예제 2, 3, 4, 5

procedure DrawLine( Canvas: TCanvas );

begin

  with Canvas do

  begin

    SetMapMode( MM_LOMETRIC ); // mm 단위



    Pen.Width := 1;

    MoveTo( 100, -100 );

    LineTo( 2000, -100 );



    Pen.Width := 3;

    MoveTo( 100, -200 );

    LineTo( 2000, -200 );



    Pen.Width := 5;

    MoveTo( 100, -400 );

    LineTo( 2000, -400 );



    Pen.Width := 10;

    MoveTo( 100, -600 );

    LineTo( 2000, -600 );



    Pen.Width := 20;

    MoveTo( 100, -800 );

    LineTo( 2000, -800 );



    Pen.Color := clRed;

    Brush.Color := clYellow;

    Ellipse( 100, -1000, 2000, -1200 );



    Pen.Color := clGreen;

    Brush.Color := clBlue;

    Rectangle( 100, -1400, 2000, -1600 );



    Pen.Color := clMaroon;

    Brush.Color := clAqua;

    Rectangle( 100, -1800, 2000, -2000 );

    Brush.Color := clNavy;

    Brush.Style := bsDiagCross;

    Rectangle( 100, -2200, 2000, -2500 );

  end;

end;



procedure TMain_Form.Button1Click(Sender: TObject);

begin

  Printer.BeginDoc;

  DrawLine( Printer.Canvas );

  Printer.EndDoc;

end;







문자출력

// 예제 6 폰트의 Baseline, Ascent, Descent영역 알기

procedure TMain_Form.Button2Click(Sender: TObject);

var

  Metrics : TTextMetric;

begin

  Printer.BeginDoc;



  with Printer.Canvas do

  begin

    Brush.Style := bsClear;



    SetMapMode( Handle, MM_LOMETRIC );

    Font.Name := '굴림체';

    Font.Height := 300;



    GetTextMetrics( Handle, Metrics );

    TextOut( 50, -500 + Metrics.tmAscent, 'Delphi델파이' );



    Pen.Width := 2; MoveTo( 0, -500 );

    LineTo( 2000, -500 );

    Pen.Width := 1;



    MoveTo( 0, -500 + Metrics.tmAscent );

    LineTo( 2000, -500 + Metrics.tmAscent );



    MoveTo( 0, -500 - Metrics.tmDescent );

    LineTo( 2000, -500 - Metrics.tmDescent );

  end;



  Printer.EndDoc;

end;



// 예제 7-1 베이스라인에 맞추어 줄단위로 출력하기

procedure TextOutBase( X, Y: Integer; Text: String );

var

  Metrics : TTextMetric;

begin

  with Printer.Canvas do

  begin

    GetTextMetrics( Handle, Metrics );

    TextOut( X, Y + Metrics.tmAscent, Text );

  end;

end;



procedure TMain_Form.Button3Click(Sender: TObject);

const

  Text1 = 'Delphi';

  Text2 = 'print';

  Text3 = 'Superpage';

  Text4 = 'Yang Byoung Kyu';

  Text5 = '델마당';

var

  Len : Integer;

begin

  Printer.BeginDoc;

  with Printer.Canvas do

  begin

    SetMapMode( Handle, MM_LOMETRIC );



    Font.Name := 'Times New Roman';

    Brush.Style := bsClear;

    Len := 100;

    Font.Height := 200;



    TextOutBase( Len, -300, Text1 );

    Inc( Len, TextWidth( Text1 + ' ' ) );

    Font.Height := 120;



    TextOutBase( Len, -300, Text2 );

    Inc( Len, TextWidth( Text2 + ' ' ) );

    Font.Height := 60;



    TextOutBase( Len, -300, Text3 );

    Inc( Len, TextWidth( Text3 + ' ' ) );

    Font.Height := 50;



    TextOutBase( Len, -300, Text4 );

    Inc( Len, TextWidth( Text4 + ' ' ) );

    Font.Name := '굴림';

    Font.Height := 100;



    TextOutBase( Len, -300, Text5 );

    MoveTo( 0, -300 );

    LineTo( 2000, -300 );

  end;



  Printer.EndDoc;

end;



//예제 7-2 박스안에 출력하기

procedure TMain_Form.Button4Click(Sender: TObject);

const

  DrawFormat : array[0..8] of UINT = (

    DT_LEFT or DT_TOP, DT_CENTER or DT_TOP,

    DT_RIGHT or DT_TOP, DT_LEFT or DT_VCENTER,

    DT_CENTER or DT_VCENTER, DT_RIGHT or DT_VCENTER,

    DT_LEFT or DT_BOTTOM, DT_CENTER or DT_BOTTOM,

    DT_RIGHT or DT_BOTTOM );

  Texts: array[0..8] of String = ( '왼쪽 위', '중간 위', '오른쪽 위',

                                                 '왼쪽 중간','중간', '오른쪽 중간',

                                                 '왼쪽 아래','중간 아래','오른쪽 아래');

var

  ARect: TRect; i: Integer;

begin

  ARect := Rect( 0, -600, 1000, -1600 );



  Printer.BeginDoc;

  with Printer.Canvas do

  begin

    SetMapMode( Handle, MM_LOMETRIC );

    Font.Name := '굴림체';

    Font.Height := 50;

    Brush.Style := bsClear;



    for i:= 0 to 8 do

      DrawText( Handle, PChar( Texts[i] ), Length( Texts[i] ), ARect, DT_SINGLELINE or DrawFormat[i] );



    with ARect do

      Rectangle( Left, Top, Right, Bottom );

  end;

  Printer.EndDoc;

end;





//예제 7-3 DrawText를 이용해서 좌,우, 중앙 정렬하기

procedure TMain_Form.Button5Click(Sender: TObject);

const

  DrawFormat: array[0..2] of UINT = ( DT_LEFT, DT_CENTER, DT_RIGHT );

  Texts: array[0..4] of String = ( 'Delphi', 'print', 'Superpage', 'YYY MMM DDD', '델파이' );

var

  ARect: TRect; i, j: Integer;

begin

  ARect := Rect( 200, 0, 1800, -2000 );



  Printer.BeginDoc;

  with Printer.Canvas do

  begin

    SetMapMode( Handle, MM_LOMETRIC );



    Font.Name := '굴림체';

    Font.Height := 50;

    Brush.Style := bsClear;



    for i:= 0 to 4 do

    begin

      for j:= 0 to 2 do

        DrawText( Handle, PChar( Texts[i] ), Length( Texts[i] ), ARect, DT_SINGLELINE or DT_BOTTOM or DrawFormat[j] );



      Dec( ARect.Bottom, 100 );

    end;

  end;

  Printer.EndDoc;

end;





// 예제 8 장평, 각도 조절하기
procedure TMain_Form.Button6Click(Sender: TObject);
var
  LogFont: TLogFont;
  OldFont, NewFont: HFONT;
begin
  Printer.BeginDoc;

  with Printer.Canvas do
  begin
    SetMapMode( Handle, MM_LOMETRIC );
    Font.Name := '굴림체';
    Brush.Style := bsClear;

    if GetObject(Font.Handle, SizeOf(LogFont), @LogFont) <> 0 then
    begin
      with LogFont do
      begin
        lfHeight := 100;
        lfWidth := 70;
        lfEscapement := -300;
      end;

      NewFont:= CreateFontIndirect( LogFont );
      OldFont := SelectObject( Handle, NewFont );
      TextOut( 1200, -200, '글씨를 쓰자' );
      NewFont := SelectObject(Canvas.Handle,OldFont);
      DeleteObject(NewFont);
    end;
  end;
  Printer.EndDoc;
end;

음영처리

//RGB를 이용한 음영
procedure TMain_Form.Button7Click(Sender: TObject);
var

  i: Integer;

begin

  Printer.BeginDoc;

  SetMapMode( Printer.Handle, MM_LOMETRIC );

  with Printer.Canvas do

  begin

    for i:= 0 to 255 do
    begin
      Pen.Color:= RGB( i, i, i );
      Brush.Color:= Pen.Color;

      Brush.Style:= bsSolid;

      Rectangle( 0, -( i * 10 ), 500, -( ( i+1 ) * 10 ) );

      Brush.Style:= bsClear;

      if i mod 10 = 0 then

        TextOut( 550, -( i * 10 ),  Format( 'RGB( %d, %d, %d );', [i,i,i] ) );

    end;

  end;

  Printer.EndDoc;

end;



//비트맵 브러시를 이용한 음영

procedure TMain_Form.Button9Click(Sender: TObject);

var

  i: Integer;

begin

  Printer.BeginDoc;

  SetMapMode( Printer.Handle, MM_LOMETRIC );



  with Printer.Canvas do

  begin

    Brush.Bitmap := Image_Brush1.Picture.Bitmap;

    Rectangle( 1700, 0, 2000, -400 );



    Brush.Bitmap := Image_Brush2.Picture.Bitmap;

    Rectangle( 1700, -400, 2000, -800 );



    Brush.Bitmap := Image_Brush3.Picture.Bitmap;

    Rectangle( 1700, -800, 2000, -1200 );



    Brush.Bitmap := Image_Brush4.Picture.Bitmap;

    Rectangle( 1700, -1200, 2000, -1600 );

  end;

end;
